Multi-part manhole covers for large openings – pump rooms, water tanks, valve chambers, sump pits and plant rooms – where one single cover would be too heavy to lift. The opening is split into smaller panels resting on removable cross beams, so each panel can be lifted safely and the whole opening can be cleared when needed. Supplied across Dubai, Abu Dhabi, Sharjah and the UAE.
Options
| Material | Stainless steel SS 304/316, aluminium |
|---|---|
| Top | Solid top (chequer plate, non-slip) or recessed tray for tile, stone or paving infill |
| Configuration | Double-opening, triple or multi-part covers with removable intermediate beams |
| Sealing | Single or double seal, odour gasket where needed |
| Accessories | Lifting keys, locking bolts |
| Duty | Light-duty (pedestrian) to heavy-duty, matched to the location |
Where multi-part covers are used
- Pump rooms and booster pump chambers
- Underground and roof water tanks
- Valve and meter chambers
- Sump pits, grease and oil interceptor chambers
- Plant rooms, service corridors and podium decks
How to specify a multi-part cover
- Clear opening – length × width of the chamber.
- Top finish – solid chequer plate, or recessed with the infill depth (tile, stone or paving).
- Traffic – pedestrian only, or vehicles.
- Location – indoor, outdoor, wet area or coastal (we will suggest SS 316 or aluminium).
- Access – how often the chamber is opened, and whether locking is needed.
Covers are made to your drawings and supplied with shop drawings for consultant approval.
Multi-Part Manhole Covers in Dubai, Abu Dhabi & Sharjah
We supply multi-part manhole covers to sites across Dubai, Abu Dhabi, Sharjah and the other emirates, and to Saudi Arabia, Oman, Qatar, Kuwait and Bahrain. Contact Alphatek, your multi-part manhole covers supplier in the UAE, for prices, availability and submittal documents.
Frequently asked questions
Why choose a multi-part cover instead of one large cover?
A single cover over a large opening becomes too heavy and awkward to lift by hand. Splitting it into panels keeps each piece manageable while the beams carry the load.
Can the cross beams be removed?
Yes. The intermediate beams are removable, so the full opening can be cleared to bring pumps or equipment in and out.
Do you supply recessed multi-part covers for tiled floors?
Yes. Recessed multi-part covers take tile, stone or paving infill so the cover matches the surrounding floor.
Which material should I choose?
SS 316 for wet, coastal and hygienic areas, SS 304 for general indoor use, and aluminium where light weight and corrosion resistance matter.
Request a quotation
Send the size, quantity, finish and delivery location to sales@alphatek.ae, call +971 54 466 7243 or use our quote form. We usually reply the same or next working day, with drawings and submittals for consultant approval where needed. Supplied to Dubai, Abu Dhabi, Sharjah and across the UAE & GCC.
See the full range: Manhole covers.
